AW-D307
Addressable Sounder Beacon
The AW-D307 is an addressable sounder beacon (strobe sounder) designed for life safety and fire alarm notification applications. It integrates high-decibel audible signaling with a visual strobe light into a single device connected directly to a bus-type addressable fire alarm control panel loop (such as the Asenware AW-FP100 / AW-FP300 series).
Typical Applications
The AW-D307 is typically installed in commercial and industrial settings requiring addressable fire signaling, including:
- High-rise residential and office buildings
- Hotels, shopping malls, and entertainment venues
- Manufacturing plants, warehouses, and industrial facilities
- Schools, hospitals, and public facilities
Key Features & Functionality
- Dual Notification: Provides both high-intensity flashing LED visuals and high-volume acoustic alarms to ensure rapid evacuation during emergencies.
- Addressable Communication: Connects to the main alarm panel loop, allowing individual address identification and remote triggering/monitoring.
- Modular Design: Consists of an upper cover assembly and an independent base for easy field installation, wiring, and maintenance.
- Flexible Mounting: Designed for both wall-mount and ceiling-mount configurations.
- High Efficiency: Uses low-power LED visual technology to reduce total power consumption on the fire loop/power bus.
Technical Specifications
Certification: LPCB (Loss Prevention Certification Board)
Standard: EN54-3/EN54-23
